Platformă electrică pentru ridicare HELI JS1212ELi

Electric Lifting Platform HELI JS1212ELi

Maximum working height, m: 13.9
Maximum platform height, m: 11.9
Working load, kg: 320
Working load for extended platform, kg: 120
Length x Width x Height, mm: 2.4 x 1.15 x 2.6

€17,800

360,450 MDL

Request a quote

Contact a sales representative Contact us on WhatsApp

or fill in the contact form

Contact details

Customer type

Individual Order under your personal name Legal entity Order on behalf of a company

Phone

Full name

We use your details to answer your request and send you a quote. Your name and phone number reach our sales team as soon as you go to step 2, even if you do not finish the request. Privacy policy

Delivery & payment

Delivery method

Pickup from store Pick up the product from our location Delivery Delivery to the provided address

Delivery address / Location (optional)

Payment

Bank transfer Invoice / bank details on request Pay at store Pay at our location (POS / cash)

Quote request details (optional)

Company details

Company

IDNO

Please enter 13 digits (IDNO)

VAT (optional)

Legal address (optional)

IBAN account (optional)

HELI JS1212ELi electric lifting platform – 13.9 m working height, Li-Ion battery

The JS1212ELi is an electric lifting platform with a lithium-ion battery, designed for professional work at height — 13.9 m maximum working height, 320 kg load and zero battery maintenance.

Li-Ion battery and performance

25.6V / 220Ah lithium-ion battery — over 4,000 charge-discharge cycles, over 75% of initial capacity retained.
Battery warranty: 5 years or 10,000 operating hours.
Zero maintenance — fully sealed battery.
Charging capacity up to 2C and discharge up to 5C for maximum productivity.
Stable performance even at low temperatures.

Main technical specifications

Maximum working height: 13.9 m / Maximum platform height: 11.9 m
Working load: 320 kg (120 kg on the extended platform)
Platform extension length: 1.0 m
Travel speed: 3.2 km/h
Lifting/lowering speed: 52 s
Weight: 2,950 kg

Recommended applications

Recommended for:

Work at height in industrial, logistics or commercial spaces
Intensive use where low running costs matter
Companies that want to eliminate downtime caused by battery maintenance

Maximum working height, m

13.9

Maximum platform height, m

11.9

Working load, kg

320

Working load for extended platform, kg

120

Length x Width x Height, mm

2.4 x 1.15 x 2.6

Platform extension length, m

1.0

Clearance in retracted position, mm

Clearance in extended position, mm

Wheelbase, m

1.85

Minimum outer turning radius, mm

2.2

Lifting electric motor power, m

3.3 / 0.7x2

Travel speed, km/h

3.2

Lifting / lowering speed, s

Battery voltage, V/Ah

25.6/220

External battery charger, V/Ah

24/36

Maximum gradeability

Working gradeability

1.5 / 3

Tyre dimensions, mm

381x129

Weight, kg

2950

HELI is the largest forklift manufacturer in China and one of the global leaders in the material handling equipment industry. With a history dating back to 1958, HELI is renowned for its reliability, innovation, and diverse range of equipment for industrial applications.

The HELI JS1212ELi model is equipped with a lithium-ion battery, designed to deliver high performance and minimal maintenance.

Lifespan: Over 4,000 charge-discharge cycles, maintaining over 75% of capacity
Warranty: 5 years or 10,000 operating hours
Maintenance: Maintenance-free (sealed battery)
Low-temperature performance: Reliable operation in low-temperature conditions
Charge/discharge capability: Up to 2C for charging and 5C for discharging

AC power to platform 110~220V/10A

Anti-collision platform

Pneumatic line to platform

Foldable guardrail
