Motor Grader CDM7180

Motor Grader CDM7180 – 15.7 Tons, 132 kW Cummins Engine

The CDM7180 is the range-topping motor grader — a heavy machine with a 132 kW Cummins engine and a 3,658 mm grading blade, built for large-scale road infrastructure and earthworks projects where precision and productivity matter as much as raw power.

Cummins Engine and 6-Speed Transmission

• Cummins 6BTA5.9 engine, 132 kW / 2200 rpm, maximum torque 750 N·m.
• 6-speed transmission, from 6.5 km/h for precision grading up to 49.2 km/h for fast movement around the site.
• Adjustable grading blade, 3,658 mm length, with a maximum lift of 450 mm and a working depth of 535 mm.
• High-pressure hydraulic system (17.5 MPa), pump flow 99 l/min — fine blade control even on difficult surfaces.
• Minimum turning radius of 7,300 mm, for good maneuverability in a machine of this capacity.

Key Technical Specifications

• Operating weight: 15,720 kg
• Engine: Cummins 6BTA5.9, 132 kW
• Maximum torque: 750 N·m
• Travel speed: 6.5 – 49.2 km/h (6 gears)
• Blade length: 3,658 mm / Blade thickness: 20 mm
• Fuel tank: 370 l / Hydraulic system: 65 l

Recommended Applications

Recommended for:

• Road construction and road infrastructure maintenance
• Earthworks and grading over large surfaces
• Contractors and construction companies that need precision and productivity on large-scale projects
